The 1st row and 2nd row can select different destinations
(second delegation mode) by pressing the [2ND DELG]
button on the cross-point pad, turning it on.
SHIFT button
The [SHIFT] button function is assigned to the button on
the right-hand end, and is used to toggle between the
shifted and unshifted states of the button row.
The operation of the [SHIFT] button in second delegation
mode can be set to one of the following modes in the Setup
menu.
• The shifted state is selected while the button is pressed
(hold mode).
• Every time the button is pressed, it toggles between
shifted and unshifted states (lock mode).
You can also disable the [SHIFT] button function for the
3rd row/4th row cross-point buttons.
For details, see “Setting the Router Operation Mode”
(page 418).
Delegation button/cross-point button numbers
The button numbers are labeled on the delegation/cross-
point buttons. The button numbers are the same as for
AUX bus control block (AUX bus operation mode).
However, button numbers 65 to 70 are unavailable for 1st
row/2nd row delegation buttons.
For details, see “Button numbers in the AUX bus control
block (AUX bus operation mode)” (page 80).
b Display
Six types of display mode can be selected, according to the
information to display. The display mode is switched using
the display mode buttons on the cross-point pad.
The following information can be shown on the display.
• Settings of buttons on the 1st row to 4th row (destination
name, source name)
• Names of sources selected on each destination for the
delegation buttons in the 1st row and 2nd row
• When the [SHIFT] button function is set, “SHFT”
appears on the display. When the shifted state is selected,
“SHFT” is highlighted in reverse video, and the button
information also toggles to show the shifted display.
• When the [DEST DISP MODE] button is pressed,
turning it off, the 1st row and 2nd row information
shown on the display toggles to the source names
selected for the destination.
The information shown in each display mode is configured
in the Setup menu. The display can also be subdivided (top
and bottom) to display two pieces of information.
For details, see “Setting the Display Mode of the Cross-
Point Control Block/AUX Bus Control Block” (page 437).
c Cross-point indicators
Not used in router operation mode.
d Cross-point pad
For details about the cross-point pad, see “Cross-point
pad” (page 48) in AUX bus operation mode.
Menu Panel
The menu panel is used for menu operations.
Name Description
1st row When the [2ND DELG] button is lit:
Selects a destination to assign in
the 3rd row.
When the [2ND DELG] button is not
lit:
• Selects a destination to assign in
the 3rd row and 4th row.
• Selects a destination on the
unshifted state of a delegation
button in the 1st row.
2nd row When the [2ND DELG] button is lit:
Selects a destination to assign in
the 4th row.
When the [2ND DELG] button is not
lit:
• Selects a destination to assign in
the 3rd row and 4th row.
• Selects a destination on the shifted
state of a delegation button in the
2nd row.
3rd row When the [2ND DELG] button is lit:
Selects a source for the destination
selected in the 1st row.
When the [2ND DELG] button is not
lit:
• Selects a source for the
destination selected in the 1st
row or 2nd row.
• You can select a source on the
shifted state of a button while
pressing the [SHIFT] button.
4th row When the [2ND DELG] button is lit:
Selects a source for the destination
selected in the 2nd row.
When the [2ND DELG] button is not
lit:
Selects a source on the shifted
state for the destination selected in
the 1st row or 2nd row.
Notes
