1E. Parts Description
[Figure 1E-A. Low-Pressure & High/Low Burner]
[Figure 1E-B. Mid-Pressure & Progressive High/Low, Modulating Burner]
GW 50 A5
0036
GW 50 A5
0036
4
2
1
5
3
6
10
7
8
9
14
1112151613
KS 50A FF F/G KS 50A FF F/G
GW 50 A5
0036
GW 50 A5
0036
1319
GW 50 A5
0036
4
2
1
5
3
6
10
7
8
9
14
1112181715
1 Blast Tube
2 Comb. Head
3 Flame Rod
4 Electrode
5 Gas Manifold
6 Burner Housing
7 Pressure S/W
8 Ignition Transformer
9 Burner Controller
10 Butterfly Valve
11 Safety Shut-off Valve
12 Leak Switch
13 Damper Motor
14 Fan Motor
15 Gas Pressure Switch(Low)
16 Gas Filter(Low-Pressure)
17 Governor(Mid-Pressure/Gas Filter included)
18 Gas Pressure Switch(High)
19. Sector Regulator
