PART Ⅰ : Installation Manual
1A. Product Introduction
P-type is a forced mixing-type gas burner designed to burn both LNG and LPG, enabling simple installation and repair.
 There is no danger of backfire because it is a NOZZLE MIX TYPE in which the pressurized air and fuel gas supplied by the blower
attached to the burner burn and gets mixed simultaneously in the burner's combustion head.
 The burner can be safely applied to various boilers and heaters regardless of atmospheric combustion and pressurized combustion
within the burner capacity.
 Fully automatic operation is available because the burner control unit is programmed to operate devices in proper sequence and time
for flame detection by flame ionization current or UV detector and ignition by high voltage arc flame.
These are a proportional control burner that automatically adjusts the gas combustion amount from the minimum to the maximum or
HI/LOW control burner that is controlled from about 100% to 50%. Ignition and extinguishing are conducted at the minimum gas level,
leading to very low ignition noise and extinguishing noise.
1B. Burner Specifications
Please refer to the table below for the specifications of each model of P-type burner.
[Table 1B-A. P-type Burner Specifications]
Model
Output [kcal/h]
Gas Preesure
[kpa]
Electric Supply
Motor
[kW]
Operation
Fuel
Connection
Min. Max. Power Control
P3M 180,000 450,000 2 ~ 50 220/380V 3Ø 220V 1Ø 0.74 AB / MD KS 40A
P4M 180,000 500,000 2 ~ 50 220/380V 3 Ø 220V 1Ø 0.74 AB / MD KS 40A
P5M 200,000 650,000 2 ~ 50 220/380V 3 Ø 220V 1Ø 1.5 AB / MD KS 50A
P60M 200,000 800,000 2 ~ 50 220/380V 3 Ø 220V 1Ø 1.5 AB / MD KS 50A
P7M 300,000 1,500,000 10 ~ 50 220/380V 3 Ø 220V 1Ø 2.2 PR / MD KS 50A
P72M 500,000 1,800,000 10 ~ 50 220/380V 3 Ø 220V 1Ø 3.0 PR / MD KS 50A
P8M 700,000 2,500,000 10 ~ 50 220/380V 3 Ø 220V 1Ø 5.5 PR / MD KS 50A
P92M 700,000 2,500,000 10 ~ 50 220/380V 3 Ø 220V 1Ø 5.5 PR / MD KS 50A
P13M 1,000,000 3,600,000 10 ~ 50 220/380V 3 Ø 220V 1Ø 11 PR / MD KS 50A
P15M 1,000,000 4,500,000 10 ~ 50 220/380V 3 Ø 220V 1Ø 11 PR / MD KS 50A
P650M 1,300,000 6,500,000 10 ~ 50 220/380V 3 Ø 220V 1Ø 18.5 PR / MD DIN 65A
P1030M 2,000,000 13,000,000 10 ~ 50 220/380V 3 Ø 220V 1Ø 30 PR / MD DIN 65A
[Table 1B-B. P-type Low-Nox Burner Specifications]
Model
Output [kcal/h]
Gas Preesure
[kpa]
Electric Supply
Motor
[kW]
Operation
Fuel
Connection
Min. Max. Power Control
P4M LX 180,000 450,000 2 ~ 50 220/380V 3 Ø 220V 1Ø 0.74 AB / MD KS 40A
P5M LX 200,000 600,000 2 ~ 50 220/380V 3 Ø 220V 1Ø 1.5 AB / MD KS 50A
P60M LX 200,000 800,000 2 ~ 50 220/380V 3 Ø 220V 1Ø 1.5 AB / MD KS 50A
P72M LX 500,000 1,350,000 10 ~ 50 220/380V 3 Ø 220V 1Ø 3 PR / MD KS 50A
P8M LX 700,000 2,000,000 10 ~ 50 220/380V 3 Ø 220V 1Ø 5.5 PR / MD KS 50A
P92M LX 700,000 2,400,000 10 ~ 50 220/380V 3 Ø 220V 1Ø 7.5 PR / MD KS 50A
P13M LX 1,000,000 2,800,000 10 ~ 50 220/380V 3 Ø 220V 1Ø 11 PR / MD KS 50A
P15M LX 1,000,000 3,600,000 10 ~ 50 220/380V 3 Ø 220V 1Ø 11 PR / MD KS 50A
P650M LX 1,300,000 4,800,000 10 ~ 50 220/380V 3 Ø 220V 1Ø 18.5 PR / MD DIN 65A
AB – High/Low
PR – Progressive High/Low
MD – Modulating
