Sophos AP10 User Manual

Sophos Access Points Operating Instructions
United Kingdom Sales:
Tel: +44 (0)8447 671131
Email: sales@sophos.com
North American Sales:
Toll Free: 1-866-866-2802
Email: nasales@sophos.com
Boston, USA | Oxford, UK
© Copyright 2011. Sophos Ltd. All rights reserved.
All trademarks are the property of their respective owners.
Sophos Operating Instructions 12.11v1.dNA
Technical specifications
Sophos AP50
LAN interfaces 1 x 10/100/1000 Base-T
Wireless interfaces 802.11 a/b/g/n 2.4 GHz or 5 GHz
Antennas 2 x 2.4G/5G dual-band antenna
Power supply 100-240 VAC, 50/60 Hz, max. 0.3 A
Weight 370 g / 0.816 lbs
Dimensions W x H x D 217 x 28 x 138 mm
Chassis Plastic housing, white
Mounting Desktop / wall
Temperature 0°C to 40°C (operating)
-20°C to 70°C (storage)
10% to 90% relative humidity non-considering
Certifications CE, FCC, RoHS, WEEE
PoE injector PD-9001GR/AC
Input power 100-240 VAC, 50/60 Hz, max. 0.8 A
Power over Ethernet
output (max.)
Output power voltage: 55 VDC
Output power: 30 W
802.3at compliant
Weight 200 g / 0.44 lbs
Dimensions W x H x D 53 x 33 x 140 mm
Chassis Plastic housing
Mounting Desktop / wall
Temperature 0°C to 40°C (operating)
-20°C to 70°C (storage)
10% to 90% relative humidity non-considering
Certifications CE, FCC, VCCI, UL, GS, RoHS, WEEE

Sophos AP10 Specifications

General

Brand	Sophos
Model	AP10
Category	Wireless Access Point
Language	English
