SoundCraft UI12 User Manual

Ui12, Ui16 User Manual
5.4: DYNAMICS
CHANNEL EDIT > DYNAMICS
5.4: DYNAMICS
ATTACK
Adjust the compressor Attack
This is the speed at which the compressor reacts and reaches the attenuation set by the RATIO parameter.
RELEASE
Adjust the compressor Release
This is the speed at which the compressor returns to ‘no attenuation’ after the signal level has fallen below the
threshold level.
GRM - METERING
Gain reduction metering
There are three meters: Input signal, output signal, and a meter showing the amount of attenuation currently
being applied due to the dynamics processing.
GAIN
Adjust the compressor Make-up Gain
Compression results in an overall reduction in signal level, so a GAIN control is provided to ‘make-up’ the lost gain.
Heavy compression plus make-up gain can often result in an increase in perceived overall loudness.
RESET
Reset the Dynamics for this channel to default values
BYPASS
Bypass the Dynamics for this channel

SoundCraft UI12 Specifications

General

Channels	12
Mic Preamps	4
Hi-Z Inputs	2
USB Playback	Yes
USB Audio Interface	2-in/2-out
Wireless Control	Yes
Mic Inputs	4 x XLR
Effects	Reverb and delay
Connectivity	Wi-Fi
Wi-Fi	Built-in
Power Supply	External
Dimensions	177mm x 297mm
Weight	2.29 kg
Line Inputs	4 x XLR/TRS combo jacks (shared with mic inputs), 2 x RCA (L/R)
Control	Remote control via HTML5 compatible web browser
