1.3: SPECIFICATIONS
INTRODUCTION > SAFETY
1.3: SPECIFICATIONS
Ui12, Ui16 User Manual
SOUNDCRAFT Ui TYPICAL SPECIFICATIONS
• Frequency Response
20Hz-20kHz +/- 0.25 dB
• THD
-20dBFS @ 1kHz <0.006%
• Noise
Residual Noise -96dBu
Mic Input E.I.N.22Hz-22kHz unweighted:
-109dB EIN
Mix Noise masters at unity < -90dBu
1 input to Mix at Unity gain < -86dBu
• Cross Talk (@1kHz)
Channel ON attenuation <120dB
Channel Fader Attenuation <120dB
Mic-Mic -103dB@ 1kHz, -93dB@ 10kHz
Line-Line -103dB@ 1kHz, -93dB@ 10kHz
• Input Gain
Mic/Line Gain -40dB to +50dB (0.1dB steps, Step
accuracy depends on size of fader in GUI)
• Gate
Threshold -inf to +6dB
Auto Attack
Auto Release
• Compressor
Threshold -90dB +6dB
Ratio 1:1 - 50:1
Attack 1ms - 400ms
Release 10ms - 2000ms
Makeup Gain -24dB - +48dB
• EQ Channel
4 band parametriq EQ
Each Band Freq 20Hz to 22kHz
Q .05 - 15
Gain -20dB to +20dB
HPF 20Hz to 1kHz
• De-esser
Threshold -90dB to 6dB
Ratioinnityto1:1
Frequency 2kHz to 15kHz
• EQ Outputs
32 band GEQ, 20Hz - 20KHz +-15dB
• Compressor outputs
Threshold -90dB +6dB
Ratio 1:1 - 50:1
Attack 1ms - 400ms
Release 10ms - 2000ms
Makeup Gain -24dB - +48dB
• dbx® AFS on all outputs
12parametricEQ’s(6xed,6oating)
• Latency
Mic in - ADC -DSP -DAC - Line output 1.8ms
• Input and Output Levels
Mic Input +20dBu max
Line input +20dBu max
Mix output +23dBu max
Headphone outputs 500mW 1 output used
(@120Ω),380mwbothoutputsused
• Input and Output Impedances
Micinput10kΩ
LineInput10kΩ
Hi-ZInput250kΩ
Outputsallat100Ω
• USB
Max Current 500mA
Max Current available to all ports: 900mA
• Power
Consumption (typical) < 25W
AC input voltage range 88-265VAC auto sensing
AC frequency 47-63Hz
• Operating Conditions
Temperature range 5°C - 45°C
Humidity 0%-90%
Storage Temperature -20°C to 60°C
E & OE.
Soundcraft reserves the right to change
specicationsandorimagesinthismanualwith-
out notice.
