SoundCraft UI12 User Manual

Ui12, Ui16 User Manual
7.0: FX EDIT
FX EDIT
7.0: FX EDIT
Digital FX are used in all types of audio to help create depth and colour to a mix. The Ui12 has three
internal Lexicon FX processors: Reverb, Delay, and Chorus. The Ui16 has an additional processor that
can either be an additional reverb or delay.
There are dedicated FX Sends and Returns for the internal FX - simply adjust the corresponding FX
Send level and bring up the level of the FX Return channel to incorporate FX into your mix.
See section 4.4 for more details of FX Sends.
FX Edit panels have Preset Save / Recall, and Fader-based parameter adjustment with numeric LCD-
style numeric display.

SoundCraft UI12 Specifications

General

Channels	12
Mic Preamps	4
Hi-Z Inputs	2
USB Playback	Yes
USB Audio Interface	2-in/2-out
Wireless Control	Yes
Mic Inputs	4 x XLR
Effects	Reverb and delay
Connectivity	Wi-Fi
Wi-Fi	Built-in
Power Supply	External
Dimensions	177mm x 297mm
Weight	2.29 kg
Line Inputs	4 x XLR/TRS combo jacks (shared with mic inputs), 2 x RCA (L/R)
Control	Remote control via HTML5 compatible web browser
