Ui12, Ui16 User Manual
APPENDIX 03: F/W UPDATE
Firmware Update Build xxxx
APP03: F/W UPDATE
AUX levels include:
- Aux Levels
- Aux send Mute
- Aux master Mute
- Aux Pre/Post
- Aux Pan if stereo linked
- Copy mix
AUX Processing include:
- EQ, DYN
- AFS2
MIX levels include:
- input channel, Line L/R, FX masters, SG’s Levels
- input channel, Line L/R, FX masters, SG’s channel Pan
- input channel, Line L/R, FX masters, SG’s channel Mutes (including Mute Groups)
MIX processing include:
Input channels, Line L/R, FX masters, SG’s should include:
- (Digitech for CH 1/2) EQ, DYN, FX Send (including FX send Mute)
NOTE:Hi-ZforCH1/2canonlybeconguredbyaloggedinuser
MIX gain include:
Input channel gain, Phantom Power, Phase, Hi-Z
Player include:
- All features of the media player/recorder
- All level, Pan, Mute, processing (EQ, DYN, FX Send)
MASTER level include:
- Master Level
- Master Balance
MASTER processing include:
- Master EQ, DYN
- Master AFS2
SHOWS include:
- LOAD/SAVE/RENAME/DELETE of Snaphots
- LOAD/NEW/RENAME/IMPORT/EXPORT/DELETE of Shows
- MIXER RESET
- CHANNEL SAFES
GLOBAL SETTINGS include:
-AllGlobalsettingsasdenedontheSETTINGS-->SETTINGStab-->GLOBALoptionslist
- This includes such option as Headphone out mode, Solo routing, Solo mode, etc.
NOTE: Solo, Mute FX, and Mute All are only available to a logged in user.

SoundCraft UI12 Specifications

General

Channels	12
Mic Preamps	4
Hi-Z Inputs	2
USB Playback	Yes
USB Audio Interface	2-in/2-out
Wireless Control	Yes
Mic Inputs	4 x XLR
Effects	Reverb and delay
Connectivity	Wi-Fi
Wi-Fi	Built-in
Power Supply	External
Dimensions	177mm x 297mm
Weight	2.29 kg
Line Inputs	4 x XLR/TRS combo jacks (shared with mic inputs), 2 x RCA (L/R)
Control	Remote control via HTML5 compatible web browser
