IV. Installation
PixiePromaybemountedusingtheplasticsurface-mountingbox(included),orusingastandard
four-gangwallbox(mustbepurchasedseparately).
Warning:ThePX2-MP-IRisalow-voltagedevice.NeverinstallthePixieProinanelectricalback
boxcontaininghigh-voltagewiring.ThiswouldcauseaseriouselectricaldangerandviolateUnited
States’electricalcodes.
1. Wall Surface Mounting
ThePixiePromaybesurfacemountedtomasonryordrywallwiththeincludedplasticsurfacemount
boxandanchors.
Securethesurfacemountboxtothewall.Bringthethree-conductorcablefromthecableassembly
tothebackboxandfeeditthroughoneofthecablechannels,locatedatthetopandbottomofthe
box.Wiremoldmaybeusedtoguidewiringalongthewall.
TosecurethePixieProintotheplasticmountingbox,linethecircuitboardupwiththeboxpostsand
insertsecurelyintotheplasticclasps.
CoverthePixieProfacewiththeincludedfaceplateandsecurewiththeincludedscrews.
2. Tabletop Surface Mounting
SecurethePixieProplasticsurfacemountboxtothetable.Threadthethree-conductorcablefrom
thecableassemblytothebackboxandfeeditthroughthewiringcutout.Wiremoldmaybeusedto
guidewiringalongthetable.Alternately,youmaycutanaccessholethroughthetableandrun
wiringalongtheundersideofthetable.
TosecurethePixieProintothesurfacemountbox,linethecircuitboardupwiththeboxpostsand
insertsecurelyintotheplasticclasps.
CoverthePixieProfacewiththeincludedfaceplateandsecurewiththeincludedscrews.
PlasticSurface
MountBox
(included)
Releaseclaspstoremove
PixieProfromsurfacebox
5
WallAnchors
(included)
WallAnchors
PixieProCircuit
Board
Figure 4: AssemblingthePixieProforsurfacemounting(surface-mountboxincluded)
