6 Cables and Connectors

38 EPOCH 35 GNSS System User Guide

6.1 Port 1 and 2 connectors

Figure 6.1 Port 1 connector pinouts

Pin Pinout function, Port 1 – 7-pin LEMO

1 Signal ground

2 Power ground

3TXD

4N/C

5N/C

6 + Power in

7TRXD

8N/A

9N/A
