Spectra Precision QuickMark Layout QML800 User Manual

Locate Control Points with QML800 System
When laser alignment is complete, go to benching.
Locate control points with both lasers.
Fast
Medium
Slow
Nudge – tap for
incremental
Small
movement
Laser on / off
Slow
Medium
Fast
“Start Layout” This begins Laser Alignment
Tap “Found Unit” or “Reflection”
14
Set Up QML800 at Job Site Floor
Tap and hold
appropriate shade
