Spectrum DX3 User Manual

28
The Servo Reversing feature of the DX3 is a very convenient feature when setting up a new
model. The purpose of the servo reversing function is to change the direction of the servo
rotation in relation to the wheel/trigger movement. The Servo Reversing function is available
for the steering, throttle and Channel 3 of the DX3.
Accessing the Servo Reversing Function
To access the Servo Reversing function, follow the steps below:
Press the MODE key until
REV•NORM appears on the
screen
MODE CHANNEL
ENTER
SYSTEM
Press the CHANNEL key to
select the desired channel to be
adjusted
ST = Steering
TH = Throttle
FN3 = Channel 3 (optional)
Press the INCREASE or
DECREASE keys to toggle
between REV and NORM
INCREASE DECREASE
CLEAR
DIRECT
+ –
1. Turn the transmitter power switch on.
2. Press the MODE key to access the Function Mode.
3. Press the MODE key until REV.NORM appears in small letters to the right of the screen.
4. Press the CHANNEL key to select the channel to be changed (ST = Steering, TH =
Throttle, FN3 = Channel 3).
5. Press the INCREASE or DECREASE keys to move the cursor to the desired direction.
6. To exit the Function Mode, either turn off the transmitter power switch or press the
MODE and CHANNEL keys at the same time.
Servo
Reversing
(Function Mode)
st
REV • NORM
–
Indicates curent channel:
ST = Steering
TH = Throttle
FN3 = Channel 3 (optional)
Cursor indicates current servo direction
–
