Chapter 1: Product Overview
Each network port is flanked with a pair of indicator lights. See the descriptions
below to understand what each type of light indicates.
Off. No Ethernet link present.
Solid Green LED. Ethernet link present.
Flashing Green LED. Passing Ethernet traffic.
Solid Orange LED. Gigabit Ethernet link present.
Solid Orange LED with Flashing Green LED. Gigabit
Ethernet link present with passing Ethernet traffic.
User Guide Model RAC2V1S 4
