SPHINX Project Eight - Figure 16: Right Output Amp

SPHINX Project Eight Service Manual
27
Figure 16: Right Output Amp
4
3
2
1
5
6
7
8
12 11 10
9
17 18 19 20
14
15
16
13
+V
-V
OUT
NFB
U12
DISAMPMODULE
4
3
2
1
5
6
7
8
12 11 10
9
17 18 19 20
14
15
16
13
+V
-V
OUT
NFB
U13
DISAMPMODULE
AGND
+ C59
C63V/2200U
+ C60
C63V/2200U
+ C56
C63V/2200U
+ C53
C63V/2200U
AGND
AGND
AGND
AGND
R58
1R00
R59
1R00
R60
1R00
R61
1R00
R+24V
R-24V
R+24V
R-24V
+R-OUT
-R-OUT
R66
10K0 .1%
R65
10K0 .1%
R68
10K0 .1%
R72
100K
R73
100K
AGND
AGND
R76
2x0.3 zilver
R77
2x0.3 zilver
-RV-OUT
+RV-OUT
AGND
C54
47N/PP
C55
47N/PP
C57
47N/PP
C58
47N/PP
37..40mA
37..40mA
37..40mA
37..40mA
C63
220p
C64
220p
