SPHINX Project Eight - Parts List

SPHINX Project Eight Service Manual
32
Parts List
Designator Part Type Description
B1 BRIDGE6 Bridge rectifier
B2 BRIDGE6 Bridge rectifier
B3 BRIDGE6 Bridge rectifier
B4 BRIDGE6 Bridge rectifier
B5 BRIDGE6 Bridge rectifier
B6 BRIDGE6 Bridge rectifier
C1 100NMKT Capacitor
C1 330N/PP Capacitor
C1 33p Capacitor
C1 47n Capacitor
C10 100NMKT Capacitor
C10 C25V/47U Capacitor
C10 C63V/1000U Capacitor
C100 100NMKT Capacitor
C101 100NMKT Capacitor
C102 100NMKT Capacitor
C103 100NMKT Capacitor
C104 100NMKT Capacitor
C105 100NMKT Capacitor
C106 C63V/2200U Capacitor
C107 47N/PP Capacitor
C108 47N/PP Capacitor
C109 C63V/2200U Capacitor
C11 C25V/47U Capacitor
C11 C50V/6800U Capacitor
C11 C63V/1000U Capacitor
C110 C63V/2200U Capacitor
C111 47N/PP Capacitor
C112 47N/PP Capacitor
C113 C63V/2200U Capacitor
C114 C63V/2200U Capacitor
C115 47N/PP Capacitor
C116 47N/PP Capacitor
C117 C63V/2200U Capacitor
C118 C63V/2200U Capacitor
C119 47N/PP Capacitor
C12 330N/PP Capacitor
C12 C25V/47U Capacitor
C12 C50V/6800U Capacitor
C120 47N/PP Capacitor
C121 C63V/2200U Capacitor
C122 220p Capacitor
C123 220p Capacitor
C124 220p Capacitor
C125 220p Capacitor
C13 100NMKT Capacitor
C13 C50V/330U Capacitor
C14 100NMKT Capacitor
C14 47N/PP Capacitor
C15 100NMKT Capacitor
C15 47N/PP Capacitor
C16 100NMKT Capacitor
C16 C50V/330U Capacitor
C17 C50V/330U Capacitor
C17 C50V/6800U Capacitor
C18 47N/PP Capacitor
C18 C50V/6800U Capacitor
C19 100NMKT Capacitor
C19 47N/PP Capacitor
C2 100NMKT Capacitor
C2 33p Capacitor
C2 47n Capacitor
