SPHINX Project Eight - Page 39

SPHINX Project Eight Service Manual
39
Designator Part Type Description
R69 100K Resistor
R7 10K0 Resistor
R7 22K1 Resistor
R7 51R0 Resistor
R70 100K Resistor
R71 100K Resistor
R72 100K Resistor
R73 100K Resistor
R74 2x0.3 silver Resistor
R75 2x0.3 zilver Resistor
R76 2x0.3 zilver Resistor
R77 2x0.3 zilver Resistor
R78 84K5 Resistor
R79 324R Resistor
R8 15R0 Resistor
R8 1R Resistor
R8 243R Resistor
R80 84K5 Resistor
R81 324R Resistor
R82 84K5 Resistor
R83 324R Resistor
R84 84K5 Resistor
R85 324R Resistor
R86 39K2 Resistor
R87 162R Resistor
R88 39K2 Resistor
R89 162R Resistor
R9 100R Resistor
R9 1R Resistor
R9 1R00 Resistor
R90 39K2 Resistor
R91 162R Resistor
R92 39K2 Resistor
R93 162R Resistor
R94 20K0 Resistor
R95 80R6 Resistor
R96 20K0 Resistor
R97 80R6 Resistor
R98 20K0 Resistor
R99 80R6 Resistor
RL1 REL16 Relay 24V
RL10 REL16 Relay 24V
RL11 REL16 Relay 24V
RL12 REL16 Relay 24V
RL13 REL16 Relay 24V
RL14 REL16 Relay 24V
RL15 REL16 Relay 24V
RL16 REL16 Relay 24V
RL17 REL16 Relay 24V
RL18 REL16 Relay 24V
RL19 REL16 Relay 24V
RL2 REL16 Relay 24V
RL20 REL16 Relay 24V
RL21 REL16 Relay 24V
RL22 REL16 Relay 24V
RL23 REL16 Relay 24V
RL24 REL16 Relay 24V
RL25 REL16 Relay 24V
RL26 REL16 Relay 24V
RL27 REL16 Relay 24V
RL28 REL16 Relay 24V
RL29 REL16 Relay 24V
RL3 REL16 Relay 24V
RL30 REL16 Relay 24V
RL31 REL16 Relay 24V
RL32 REL16 Relay 24V
