10.5 Cable / wire and connector data
Mains and signal connector
Termination Rising clamp plug-in terminal blocks with screw connectors
Cable size 0.2 mm² (24 AWG) to 2.5 mm² (12 AWG).
Stripping length 5 - 6 mm
Caution: Use only the connectors supplied by Spirax Sarco Ltd. Safety and Approvals may
be compromised otherwise.
Level probe cable / wire
Type High temperature
Shield type Screened
Number of cores 5
Gauge 1 – 1.5 mm² (18 - 16 AWG)
Maximum length 100 m (328 ft)
10.6 Input technical data
Level probe (conductivity)
Switching conductivity 1 µS / cm @ 25 °C, K = 0.22 (220 KΩ)
Drive ac – pulsed
