Initial Installation
Management Port Configuration
Spirent Landslide Test System Installation Guide | 23
Configure TAS IP Address mode (static/dynamic) [static]:
If static is selected, the user will be prompted to configure the TAS IP Address.
Specify the IPv4 Address for the TAS and press Enter to continue.
TAS IP Address []:
If dynamic is selected, the user will be prompted to configure the TAS Host Name.
Specify the Host Name of the TAS and press Enter to continue.
TAS Host Name []:
Note: This step only applies to a Landslide Test Server that will be communicating
with a Landslide Manager. If the Landslide Manager’s IP address is changed after
completing the Landslide installations, the Landslide Test Server configurations must
be modified to restore communication between the platforms.
13 If you are configuring a Landslide Manager and Landslide Test Servers to
communicate using the Landslide provided VPN service, type enable and press Enter
to continue with VPN configuration, otherwise press Enter to accept the default value
of disable to continue.
Modify VPN Service status (enable/disable) [disable]:
Manager Only - If enable is selected while provisioning a Landslide Manager,
answer the resulting configuration prompts.
• Specify a unique internal private IPv4 address that will not be used anywhere else
within the Landslide management network. An address such as 10.8.0.1 should
work, as this IP address is for use only within the private Landslide VPN
network. Press Enter to continue.
Enter the VPN server IP address [10.8.0.0]:
• Specify the netmask for the VPN server. Accepting the default of 255.255.255.0
by pressing Enter is recommended.
Enter the VPN server netmask (255.255.255.0) []:
TS Only - If enable is selected while provisioning a Landslide Test Server, answer
the resulting configuration prompts.
• Specify a unique Client ID for the Test Server’s VPN client, then press Enter to
continue.
Enter the Unique VPN Client ID []:
• Specify the IPv4 address of the Landslide Manager (NOT the internal IPv4
address configured above, then press Enter to continue.
Enter the host IP address (vpn server) []:
Note: If enabling the VPN service, make sure to provision the VPN settings on the
Landslide Manager first and that it is up and running before configuring VPN settings
on the Test Server.
14 A time server is defined for every platform. Landslide supports both NTP and PTP.
Specify ntp or ptp and press Enter to proceed with Time Sync Protocol
configuration.
<TAS / TS / TAS+TS>
Time Sync Protocol (ntp/ptp) [ntp]:
