Appendix A: Landslide Test Server NIC Configurations
Supported NIC Configurations and Port Names
Spirent Landslide Test System Installation Guide | 55
Table A-6. Two quad-port 10 Gbps NICs and one or two quad-port 1 Gbps, 8x 10 Gbps
ports and 4x or 8x 1 Gbps ports
Slot Card Ports
0 Unused NA
1 First quad-port 10 Gbps (L-NIC-66) eth2, eth3, eth4, eth5
2 First quad-port, 1 Gbps eth6, eth7, eth8, eth9
3 Second quad-port, 1 Gbps eth14, eth15, eth16, eth17
4 Second quad-port 10 Gbps (L-NIC-66) eth10, eth11, eth12, eth13
5 Optional L-ACC-007 or L-ACC-008
IPSec Accelerator
NA
6 Unused NA
