Spirent Landslide EDGE E10 - Page 61

Appendix A: Landslide Test Server NIC Configurations
Supported NIC Configurations and Port Names
Spirent Landslide Test System Installation Guide | 61
Table A-17. Three dual-port 10 Gbps NICs and 1x quad-port 1 Gbps NIC, 6x 10 Gbps
and 4x 1 Gbps ports (L-ACC-006 IPSec Accelerator Card optional)
Table A-16. One, two, three or four dual-port 10 Gbps NICs, 2x, 4x, 6x or 8x 10 Gbps ports
(L-ACC-006 IPSec Accelerator Card optional)
Slot Card Ports
1 Third dual-port, 10 Gbps
(AONIC)
eth6, eth7
2 First dual-port, 10 Gbps
(AONIC)
eth2, eth3
3 Second dual-port, 10 Gbps
(AONIC)
eth4, eth5
4 Fourth dual-port, 10 Gbps
(AONIC)
eth8, eth9
5 Optional L-ACC-006 IPSec
Accelerator
NA
Slot Card Ports
1 Third dual-port, 10 Gbps
(AONIC)
eth6, eth7
2 First dual-port, 10 Gbps
(AONIC)
eth2, eth3
3 Second dual-port, 10 Gbps
(AONIC)
eth4, eth5
4 First quad-port, 1 Gbps eth8, eth9, eth10, eth11
5 Optional L-ACC-006 IPSec
Accelerator
NA
