Step 2 (Figure 6):
 rotate the top part in the desired direction then slowly put down it ensuring the
coaxiality between the bottom part and the displacer;
 tighten the stud bolts G;
 remove the hanging equipment and remove the top locking device A-C-D;
 repositioning the ¾’’ NPT vent cap;
 unscrew for seven turns the stop dowel F.
Figure 6: top part orientation – Step 2
G
F
D
C
A
//
