ASP 116 EVOLUTION – INSTALLATION MANUAL
Sprinte SAS. All rights reserved , including translations.
56
3. Re-leveling test
This test has to be done once a year and recorded in the maintenance log .
This test helps you to check :
 The movement of the car with the doors opened.
 The opening of the safety chain, when the car exits the door unlocking area.
With the EvoPad application, you can easily perform this test inside the car.
Test conditions : Lift available at the floor.
Go into the assistance menu :
+ …
Choose «YES» to run the re-leveling test.
If the all conditons in are not fulfilled :
Otherwise
The doors are opening :
As indicated , by keeping or pressed , the car will move up or down
with the doors opened.
When you release the button, the car will start automatically the re-leveling operation.
If you don’t release the button, the car will stop automatically as soon as it will leave the door
unlocking zone.The “SAFE.REL.CUTOFF3 fault is recorded.
On the screen a letter gives you the position of the car:
U : the car is under level
A : the car is at the level
O : the car is over the level
At all times , press to stop the test.
to confirm
…
Your lift is back in use.
EXIT TEST ?
YES(+) NO (-)
STEP 1
STEP 2
Choose
ASSISTANCE
STEP 3
STEP 4
RELEVELLING TEST
NO
RELEVELLING TEST
YES
STEP 1
LA CABINE N’EST
PAS DISPONIBLE
MAINTAIN + OR -
TO TEST LEVEL.
MAINTAIN + OR -
TO TEST LEVEL. U
MAINTAIN + OR -
TO TEST LEVEL. A
MAINTAIN + OR -
TO TEST LEVEL. O
RELEVELLING TEST
NO
IN USE A X
AVAILABLE
ENTER
 -
 -
 -
 +
BACK
BACK
BACK
 +
