1. The four pin holes on the connecting frame are coincident with
the center of the shaft holes on the left and right sides of the boom.
2. The four pin shafts (A) are penetrated into the shaft holes of
the connecting frame lug plate (E) and the lifting boom lug plates (D) ,
and the pin shafts are fixed firmly.
