5. Outrigger operation
Outrigger composition
(1) Joint pull pin (2) Joint
(3) Outrigger cylinder (4) Main outrigger side plate
(5) Main outrigger (6) Gas spring
(7) Outrigger latch (8) Pole outrigger
(9) Pole outrigger handle (10) Feet
21 3
5 6
4
7
8
10
9
