SR SUNTOUR - OWNERS MANUAL RAIDON / XCR /XCM / XCT / M3000AL / M2025 SR SUNTOUR - OWNERS MANUAL RAIDON / XCR /XCM / XCT / M3000AL / M2025
English
9
Reinstall the plastic cover cap again..
CLIP ON
Thread the cable through the outer casing
stopper and through the cover unit hole.
Tension the cable slightly and tighten it
using a 1.5mm Allen key.
1.5mm
0.5 Nm
Unscrew the cable xing bolt using a
1.5mm Allen key
1.5mm
Install a cable end cap at the end of the
cut cable using a needle nose pliers.
Cut the cable to a proper length. Approxi-
mately 12mm is recommended.
12mm
CUT
To Next Page
