SR SUNTOUR - OWNERS MANUAL RAIDON / XCR /XCM / XCT / M3000AL / M2025 SR SUNTOUR - OWNERS MANUAL RAIDON / XCR /XCM / XCT / M3000AL / M2025
English
5
Caution
BEFORE EACH RIDE!
ŹDo you notice any cracks, dents, bent or tar-
nished parts at your suspension fork or any
other part of your bicycle? If so, please con-
sult a trained and qualied bicycle mechanic
to check your fork or bike.
ŹCan you notice any oil leaking out your fork?
Also check out hidden areas like the bottom
side of your fork crown. If so, please consult
a trained and qualied bicycle mechanic to
check your fork or bike.
ŹCompress your fork with your body weight. If
it feels too soft, relating to the proper pressu-
re to achieve an accurate SAG, inate it until
you have reached the required value. Please
also refer to chapter “ SETTING SAG”
ŹMake sure your brakes are properly installed/
adjusted and work appropriate. This also
applies to every other part of your bike like
handlebars, pedals, crank arms, seat post,
saddle etc. Also refer to the owner‘s manuals
provided by all other component manufac-
turers.
ŹMake sure your wheels are centered perfect-
ly in order to avoid any contact with your
suspension fork or brake system.
ŹIf you are using a quick release system to fas-
ten your wheel set, make sure that all levers
and nuts are adjusted properly. In case you
are using a through axle system, make sure
that all xing bolts are tightened with the
appropriate torque values.
ŹCheck the cable length and routing of your
components. Make sure they do not interfe-
re your steering actions.
ŹIf you are using reectors for on-road cyc-
ling, make sure they are clean and properly
installed.
ŹBounce your bike slightly on the ground
while looking and listening for anything
which might be loose.
FORK INSTALLATION
WARNING!
SR SUNTOUR strongly recommends that your fork is being installed by a trained and qualied
bicycle mechanic. Special knowledge and tools are essential to install SR SUNTOUR forks.
Common mechanical knowledge may not be sucient to install a SR SUNTOUR suspension
fork. If you intend to install the fork by yourself, the whole job has to be inspected by a
trained and qualied bicycle mechanic. Please note, that improperly installed forks are
extremely dangerous and can cause damage to the product, serious injuries or even death.
Note! All xing bolts have to be tightened with the proper fasting torque stated by the
manufacturers
Remove the existing fork from your bicycle. Afterwards remove the crown race from the 1.
fork.
Measure the length of your old fork’s steerer tube against the length of the SR SUNTOUR 2.
fork steerer. SR SUNTOUR suspension forks are delivered with a standard steerer tube
length of 255mm. Therefore the steerer tube may need cutting to the proper length.
INSTALLATION INSTRUCTIONS
Do not ride your bike, if one of the following test criteria can’t be passed!
Riding your bike without eliminating any defect or carrying out the neces-
sary adjustments can result into an accident, fatal injury or even death.
