SR SUNTOUR - OWNERS MANUAL RAIDON / XCR /XCM / XCT / M3000AL / M2025
QLOCK SYSTEM 15mm
ALL RAIDON 15QLC MODELS
ALL XCR 15QLC MODELS
1. SLIDE IN
3. CLOSE
4. CLOSED
2. ADJUST
C
L
O
S
E
CLICK!
Adjust until nding the proper tighte-
ning torque for closing the QR lever.
4. PULL OUT
3. PRESS + PUSH
1. CLOSED
2. OPEN
