Rack InstallatIon
RACK INSTALLATION
5. Use a 4 mm hex wrench to install two bolts with washers through the rack legs and into the
extensions. Tighten the bolts to 6-8 N
•
m (53-70 in-lb). Make sure the rack legs are set to the same
height on each side
6. Slide the rack along the connecting rods until the rack deck is horizontal.
7. Adjust the connecting rods on the rack cross brace so that there is an equal amount of tire clearance
on each side. Tighten the bolts to 6-8 N
•
m (53-70 in-lb).
