11
BATTERY INSTALLATION
1. Lift the reector/light mount.
2. Align the grooves in the top of the battery with the rails under the rack deck. Use the handle to push
the battery into the rack until the electrical contacts on the battery and rack securely connect.
Make sure the dock lock is in the unlocked position.
3. Lower the reector/light mount back down.
4. Lock the battery into the dock of the rack. Always lock the battery before riding the bike.
CONNECTOR INSTALLATION
1. Align the tab on the plug with the tab on the socket. Lift the tab on the socket and insert the plug until
it snaps into place. You will hear a click when the connector is secure.
