SRAM Ematic - Charger; Charging the Battery; LED Indicators

12
Charger
CHARGER
Notice
The battery can become permanently damaged if left completely discharged.
CHARGING THE BATTERY
1. The battery can be charged while it is installed on the rack, or it may be removed from the bike.
Recommended charging temperature is 0-40° C (32-104° F).
2. Align the arrows on the battery charge port and the round cable connector of the charger, then plug
the charger into the battery.
3. Plug the power cord of the charger into a wall outlet.
4. Charge the battery. The battery does not require full charge or discharge between charge cycles.
5. Unplug the charger from the wall outlet rst, then remove the charger from the battery.
LED INDICATORS
• Red indicates the charger has been plugged into a wall outlet.
• Yellow indicates the battery is charging.
• Flashing green indicates charging is 80% complete.
• Solid green indicates the battery is completely charged.
