20Lever Blade Installation
Cut the hose to install a new barb and compression fitting.
Apply DOT grease to the hose barb threads. Thread the hose barb
into the hose until it is flush with the end of the hose.
NOTICE
Do not overtighten the hose barb. Overtightening may cause
damage to the hose liner.
Install the compression nut onto the hose.
Thread the compression fitting over the hose barb, counter-
clockwise, until it is flush or slightly lower than the hose barb.
The compression fitting is reverse threaded.
Apply DOT grease to the outside of the compression fitting and
the threads of the compression nut.
SRAM Hydraulic Hose Cutter 2.7 - 3.2 N·m (24-28 in-lbs) 22 mm
14
15
16
17
