SRAM Guide R User Manual

19Lever Blade Removal
Remove the reservoir cap bolts from the reservoir cap.
Remove the reservoir cover and bladder from the lever body.
Pour the fluid from the brake lever body into a pan.
Separate the bladder from the reservoir cover.
Spray isopropyl alcohol on the bladder and the reservoir cover, then
clean them with a rag.
NOTICE
All components must be completely dry before reinstalling them.
Moisture residue from cleaning the bladder can leak out of the bladder
as it dries, which can be misinterpreted as a system leak.
5
T10 TORX® wrench 15 N•m (133 in-lb) 22 mm
6
7 7
8

SRAM Guide R Specifications

General

Brake Type	Hydraulic Disc
Lever Material	Aluminum
Caliper Design	2-piece
Fluid Type	DOT 5.1
Pad Material	Organic
Caliper Material	Aluminum
Piston Count	4
Rotor Size Compatibility	140mm, 160mm, 180mm, 200mm
Rotor Compatibility	CenterLine
Reach Adjust	Yes
