Lower Leg Installation
Slide the lower leg onto the upper tube enough to engage the upper Slide the lower leg onto the upper tube enough to engage the upper
bushing with the upper tube.bushing with the upper tube.
NOTICE
Make sure both wiper seals slide onto the tubes without folding the
outer lip of either seal.
The inside bottom of the lower leg should not contact the spring or The inside bottom of the lower leg should not contact the spring or
damper shafts. A gap between the shaft ends and the lower leg bolt damper shafts. A gap between the shaft ends and the lower leg bolt
holes should be visible.holes should be visible.
Position the fork at an angle with the lower leg bolt holes oriented Position the fork at an angle with the lower leg bolt holes oriented
upward. upward.
Angle a syringe fitting in each lower leg bolt hole so the fluid will only Angle a syringe fitting in each lower leg bolt hole so the fluid will only
contact the inside of the lower leg. contact the inside of the lower leg.
Inject 10 mL of suspension oil into each lower leg through the lower Inject 10 mL of suspension oil into each lower leg through the lower
leg bolt hole.leg bolt hole.
NOTICE
Do not exceed the recommended oil volume per leg as this can
damage the fork.
4
10 mL: 0w-30 10 mL: 0w-30
5
