SRAM Rockshox SID SL - Page 65

65
Lower Leg Installation
Install the black bottom bolt into the Install the black bottom bolt into the spring side spring side shaft of the lower leg. shaft of the lower leg.
Ultimate: Ultimate: Install the crush washer into the rebound adjuster nut. Install Install the crush washer into the rebound adjuster nut. Install
and tighten the rebound adjuster nut onto theand tighten the rebound adjuster nut onto the damper side damper side shaft of shaft of
the lower leg. the lower leg.
Select/Select+:Select/Select+: Install the red bottom bolt into the Install the red bottom bolt into the damper sidedamper side shaft shaft
of the lower leg.of the lower leg.
5 mm Spring Side 5 mm 6.8 N·m (60 in-lb)
Ultimate: 10 mm Damper Side 10 mm 4 N·m (35 in-lb)
8
Select/Select+: 5 mm Damper Side 5 mm 6.8 N·m (60 in-lb)
