Vehicle speed: Average speed for 4 pulses from 6 pulses (ignore the input signal for 10 seconds from
IGN1 ON)
The speed maintaining time does not contain the speed calculation time.
20 ms target input:
Wiper motor A/S (parking) terminal
100 ms target input switch
All switches except wiper motor A/S (parking) terminal
1.
2.
3.
The time indicated in each function does not include chattering processing time from switch input
changing point.
1.
2.
NO. Input Signal Name Logic Status
26 Front defogger switch ON=GND, OFF=OPEN
27 Central door lock switch
ON=GND, OFF=OPEN
28 SPWM easy access switch ON=GND, OFF=OPEN
29 Multifunction auto light switch ON=GND, OFF=OPEN
30 Turn signal light switch
ON=BAT/GND, OFF=OPEN (5.1V~9.2V)
31 SPWM (Seat Position with Memory) ON=GND (PWM), OFF=OPEN
32 Rain sensor ON=GND (DATA), OFF=BAT
33 Diagnosis ON=GND (DATA), OFF=BAT
34 Immobilizer ON=GND (DATA), OFF=BAT
35 Front door key cylinder switch ON=GND, OFF=OPEN
