Sliding Seatback reclining
Seat height & Seat cushion angle adjustment
1. OPERATION
1) Switch Operation
Seat position control: Sliding, Seatback reclining, Seat height adjustment, Seat cushion angle
adjustment.
1.
Outside rearview mirror position switch
operation: Up/Down/Left/Right (venter
position: not operative)
Mirror folding switch operation: Folding and
Unfolding
Operations in step 1 & 2 override the memory
operation and memory recall operation.
2.
3.
4.
To prevent the redundant current
consumption during motor running, the
motor starting point in each process is
delayed for 100 ms in automatic control
(memory recall). The operation sequence is
as below:
(Rear)
Outside rearview
mirror position
control
Outside rearview
mirror folding
To Next Page
