3) Rated Load
NO Description Rated Load
1 Chime bell/ Buzzer DC 12V 350mA/DC 12V 40mA (Inductive
load)
2 Front room lamp DC 12V 16W (Lamp load)
3 Ignition key hole illumination DC 12V 1.2W (Lamp load)
4 Seat belt warning lamp DC 12V 1.2W (Lamp load)
5 Seat belt warning lamp DC 12V 1.2W (Lamp load)
6 Parking brake warning lamp DC 12V 1.2W (Lamp load)
7 Door ajar warning lamp DC 12V 1.2W (Lamp load)
8 Door lock relay DC 12V 200mA (Inductive load)
9 Door unlock relay DC 12V 200mA (Inductive load)
10 Siren DC 12V 260W (Inductive load)
11 Tail lamp relay DC 12V 200mA (Inductive load)
12 Hazard relay DC 12V 200mA (Inductive load)
13 Power window relay DC 12V 200W (Inductive load)
14 Rear defogger relay DC 12V 200W (Inductive load)
15 Wiper LOW relay DC 12V 250W (Inductive load)
16 Wiper HIGH relay DC 12V 250W (Inductive load)
17 Front washer motor DC 12V 1.5A
18 Rear washer motor relay DC 12V 500 mA (Inductive load)
19 Headlamp relay DC 12V 750 mA (Inductive load)
20 Front defogger relay DC 12V 200mA (Inductive load)
21 SPWM easy access button illumination DC 12V 1.2 W (Lamp load)
