4610-00
2. SYSTEM LAYOUT
The steering pump is driven by the engine power through a belt. This pump circulates the power
steering oil from the reservoir -> steering pump -> oil supply pipe -> steering gear box -> oil
return pipe -> reservoir to perform steering operations
Linkage gear box
Power steering
pump & tank
Return hose & tube
High pressure hose
Column & shaft
Steering wheel
Lower shaft
Return line
High pressure line
Steering pump Steering return pipe Steering cylinder
