3. SECTIONAL DIAGRAM
Front Disc Brake
Tie rod end connection
Lower arm connection
Dust shield
Knuckle
Brake hose
Brake caliper
2-way piston
Air bleeder screw
Upper arm connection
Wheel bolt or hub bolt
Brake disc
Air bleeder screw
Brake pad
Brake caliper
