4) Input Signals
NO. Input Signal Name Logic Status
1 IGN1 ON=BAT (IGN "ON" or "START")
2 IGN2 ON=BAT (IGN "ON")
3 ALT_D ON=BAT (Engine running)
4 Key reminder switch IN=BAT (Key in)
5
OPEN=GND, CLOSE=OPEN
6
OPEN=GND, CLOSE=OPEN
7 Rear door switch
- OPEN (one of rear seat)=GND
- CLOSE (all rear seats)=OPEN
8 Tailgate switch OPEN=GND, CLOSE=OPEN
9 Hood switch OPEN=GND, CLOSE=OPEN
10
LOCK=OPEN, UNLOCK=GND
11
LOCK=OPEN, UNLOCK=GND
12 Rear door lock/unlock switch
- OPEN (one of rear seat)=GND
- CLOSE (all rear seats)=OPEN
13 Tailgate lock/unlock switch LOCK=OPEN, UNLOCK=GND
14 Rear defogger switch ON=GND, OFF=OPEN
15 Seat belt switch Unfastened=GND, Fastened=OPEN
16 Theft deterrent alarm select switch ON=GND, OFF=OPEN
17 Parking brake switch ON=GND, OFF=OPEN
18 Air bag collision sensor ON=200 ms Low signal, OFF = OPEN
19 Wiper motor-parking switch Parking=BAT, Rotating=GND
20 Washer switch ON=BAT, OFF=OPEN
21 AUTO switch ON=BAT, OFF=OPEN
22 Auto washer switch ON=BAT, OFF=OPEN
23 AUTO resistance 0W~51Kw (for intermittent wiping)
24 Speed sensor ON=GND (PWM), OFF=OPEN
25 IDR (saving the code) ON=BAT, ORR=OPEN
