6822-11
FATC MANUAL
636wX455hX16t
Receiver drier
Capacity 250cc
Desiccant XH-9(35cc)
Pressure switch Refrigerant pressure sensor
Heater & A/C uni
Heating capacity
Cooling capacity
Expansion valve Block type
Current consumption 180W
Refrigerant
Type R134a
Capacity
1. SPECIFICATIONS
Description FATC
Air conditioner
control panel
Rated voltage DC 12V
Operating voltage DC 9~16V
Current consumption 2A
Operating temperature
Output current from air mix door motor 0.4A
Output current from high relay 0.5
Base current for power transistor 1A
Output current from air source motor 0.55A
Output current from mode motor 0.55A
Dark current Below 2 mA Below 1.1 mA
Compressor
Pulley diameter 120mm
Maximum speed 8000RPM
Rated voltage DC 12V
Current consumption 2.2A
Compressor oil PAG RL 897 150cc
Condenser
Type MFC(6-PASS)
Size 636wX455hX16t
To Next Page
