4892-01
1. SPECIFICATIONS
1) Specifications of Active Wheel Speed Sensor
Description Specification Remark
Supplying voltage
4.5 ~ 16.0V
Output current (vehicle speed
approx. 2.75km/h)
7mA(Lo) ~ 14mA(Hi)
Operating temperature
Operating frequency
1 ~ 2,500Hz
Tightening torque
Front: 7.8~11.7 Nm
Rear: 7.8~11.8 Nm
Description
Specification
Remark
ABS
HECU
Clock frequency: 28 MHz
CPU: MCU60 (32bit)
Memory: 128~256 kb
Switch orifice
Wheel speed sensor
Active type Output: 7~14 mA
Steering wheel angle sensor
None
Sensor cluster
None
Longitudinal G sensor
4WD only (integrated in ABS HECU)
Pressure sensor
None
