Oil Level Check
Check the fluid level on a level ground with
the engine turned off. The fluid level should
be between the MIN and MAX marks on the
reservoir cap gauge.
A. HOT MAX
B. COLD MAX
C. HOT MIN
D. COLD MIN
Place the vehicle on a level ground and
start the engine and let it run at idle speed.
Turn the steering wheel several times so
that the oil temperature reaches to normal
Place the steering wheel at straight ahead
direction.
Check the oil level in the power steering oil
reservoir. Adjust the oil level between MAX
and MIN.
A.
B.
C.
D.
Oil Change
If the difference between two
measurements is below 5 mm and the level
is between MAX and MIN level, it's normal.
If it is over 5 mm, bleed air from the
system.
Open the power fluid reservoir cap and
drain the fluid completely with oil suction
device. To make it easy, turn the steering
wheel to its both ends several times.
Fill up the specified fluid into fluid
reservoir and bleed air from the steering
system.
A.
B.
Oil type
PSF-3
Capacity
(including reservoir)
below 5 mm
Engine running Engine idling
