Software description
Main window
25 TUN button
On/off switch for a carrier transmission.
Transmitting in the LPW mode is possible on any frequency, full power is available
only within the amateur radio bands.
This function can be used for tuning and adjustment purposes.
26, 27 Signal, Carrier sliders
Sliders for the output power adjustment. For signal and carrier respectively.
Slider positions are stored independently for each band and mode (AM, SSB, CW,
DIGI), and also for the low power mode (LPW) and for an external amplifier.
Note: Although the transceiver is designed to provide 15 W of output power, tested in continuous
operation at this power and has an overheating protection system, it is advisable to set, for
example, at half of the output power. This will decrease the signal by only 0.5 points on the S-
meter, but will significantly reduce power consumption and heat dissipation, and the transmitted
signal will be cleaner. If necessary, will also be an opportunity to increase the output power to the
maximum.
