ZS-1 Specifications
№ Parameter Value
Receiver
1 Frequency range 0,3 – 30 MHz
2 Sensitivity (MDS, preamp on) -141 dBm
3 Sensitivity (MDS, preamp off) -135 dBm
4 Blocking level (preamp on) -22 dBm
5 Blocking level (preamp off) -5 dBm
6 IIP2 (preamp off) 63 dBm
7 IIP3 (preamp off) 28 dBm
8 Attenuators 10, 20, 30 dB
9 Receiver bandwidth up to 100 kHz
10 Viewing bandwidth up to 4 MHz
Transmitter
11 Frequency range HF HAM bands:
10, 12, 15, 17, 20,
30, 40, 80, 160 m
12 Output power 15 W*
13 Harmonics level -50 dB
14 Non harmonics level -70 dB
15 TX bandwidth up to 10 kHz
Common characteristics
16 PC interface (data & control) USB 2.0
17 Supply voltage 12 – 15 V
18 Supply current (receive) 0,5 A
19 Supply current (transmit) 4 A
20 Size 240 х 170 х 35 mm
21 Weight 1,2 kg
* - the maximum output power of the transceiver ZS-1 in the range of 160 m, 80 m, 40 m, 20 m, 17
m, 15 m, 12 m and 10 m is 15 watts, but in the range of 30 m maximum output power is 8W.
Minimum system requirements: Windows XP/Vista/7/8 x32 / x64. USB2.0 Port.; Intel Core 2 Duo 1,5 GHz
with 2GB RAM, OpenGL 1.5 or higher
