Software settings

Operation by hotkeys and MIDI devices

7 Device List

Drop-down list to select a connected MIDI device to control the transceiver.

Note: If a MIDI device connected to the PC, is not in this list, then click the button to refresh the list

of MIDI devices.

To assign a shortcut key or control MIDI devices for the desired software function,

just click the left mouse button on the selected cell of the table (columns Keystroke

and Midi Control) and then press the desired key combination or rotate / move, for

example, the MIDI device controls.

Midi Modifier table column used to set modifiers. They can be used to allow to

set the same, for example, slider or knob of the MIDI device, to control different

functions of the software.

If there is only one tuning knob and two buttons, you can, for example, assign the

frequency control for VFO A and VFO B to this single tuning knob, switching its

function by pressing the corresponding modifier.

List of application functions available for control via keyboard or MIDI device

contains almost everything you might need for external control:

Mute – Muting the audio;

Volume Up/Down – receiving volume control;

MON On/Off – Mute CW monitor;

MON Volume Up/Down – CW monitor volume control;

Audio AGC On/Off – AGC switch;

Audio AGC Up/Down – Audio AGC switch (Fast, Medium, Slow);

Gain Threshold On/Off – AGT/MGT switch;

Adaptive/Manual Gain Threshold – switching between AGT and MGT;

Gain Threshold Up/Down – AGT/MGT level adjustment;

NB On/Off – Noise blanker switch;

NB Up/Down – Noise blanker level adjustment;

NR On/Off – Noise reduction switch;

NR Up/Down – Noise reduction level adjustment;

ANF On/Off – Automatic notch filter switch;

ANF Up/Down – Automatic notch filter level adjustment;
