SST SST-PFB-SLC - 4.1 Installing the Scanner Module

SST-PFB-SLC User’s Guide
20
4.1 Installing the Scanner Module
This illustration identifies the chassis and module components described in
the procedures in this chapter.
Warning
Disconnect system power before attempting to install,
remove, or wire the scanner.
Note
The scanner consumes 700 mA at 5 VDC.
