Using the Scanner Module as a DP Slave
57
7.5.1 Local Station
To set the local station number, issue the LocStn command with the station
number (0-126) as a parameter .
Example
LocStn 22
7.5.2 Active/Passive
To set the station to be passive, issue the command Active 0.
7.5.3 Baud Rate
To set the baud rate, issue the Baud command with the baud rate as a
parameter. Allowed values for the baud rate parameter are 9k6, 19k2, 93k75,
187k5, 500k, 750k, 1m5, 3m, 6m, and 12m.
Example
Baud 1m5
sets the baud rate to 1.5 Mbaud.
7.5.4 Other Network Options
To tell the module that there are one or more repeaters on the network, issue
the command Repeater 1 from the serial port.
To tell the module that there are FMS devices on the network, issue the
command FmsDevices1 from the serial port.
7.5.5 Displaying Network Settings
To display the current network parameter settings, issue the ShowNet
command from the serial port.
7.6 Configuring the Module as a Slave Using
COM Profibus
If you are configuring the SST-PFB-SLC as a master with its own slaves and
also as a slave to another master on the network, you must create the master
files separately. Otherwise, the SST-PFB-SLC is assigned as a slave in its
own master configuration.
