DP Master Configuration and Programming
41
Error 20h occurs if you are using old firmware with the SST ProfiBus
Configuration Tool or when you are using firmware version 1.5x or later with
the old beta of the SST configuration tool (ver 0.x).
Error 23h typically occurs when new firmware was just loaded. Issue the
ClrMas command and try downloading again.
Error 25h occurs when you use the incorrect command. Use Rec2bfXmodem
for binary files from Siemens COM PROFIBUS and RecbssXmodem for
binary files from the SST ProfiBus Configuration Tool.
5.4.3 Flash Programming Errors
The following errors may occur when programming flash memory.
5.4.4 COM PROFIBUS Address Assignment Errors
30h STS_CFG_NO_CONFIG no configuration present to
program into flash
31h STS_FLASH_BAD_ID internal flash error
32h STS_FLASH_ERASE_ERR internal flash error
33h STS_FLASH_PROG_ERR internal flash error
34h STS_FLASH_VRFY_ERR internal flash error
37h Address out of range. The address assigned in
COM PROFIBUS is outside the allowed range, for
example, P66
38h Copy table overflow. This happens when I/O
modules addresses are too fragmented. Try
putting modules at consecutive addresses,
grouping input and output modules, etc.
