Contents
v
DP Master Application Examples ................................ 45
6.1 Addressing ..................................................46
6.2 32 Discrete Output Module .........................46
6.3 32 Discrete Input Module ............................47
6.4 Example: M0/M1 Addressing ......................47
6.5 Example: Accessing Data ...........................47
6.6 Example: Using Flex I/O .............................50
Using the Scanner Module as a DP Slave .................. 53
7.1 Slave Received Data ..................................54
7.2 Slave Transmit Data ...................................55
7.3 Displaying the DP Slave Configuration .......56
7.4 Disabling DP Slave Operation ....................56
7.5 Using the Module Only as a DP Slave ........56
7.5.1 Local Station .......................................57
7.5.2 Active/Passive .....................................57
7.5.3 Baud Rate ...........................................57
7.5.4 Other Network Options ........................57
7.5.5 Displaying Network Settings ...............57
7.6 Configuring the Module as a Slave Using
COM Profibus ......................................................57
Using FDL ....................................................................59
8.1 FDL (Layer 2) Messaging ...........................60
8.1.1 Input Table I:31 ...................................60
8.2 FDL Messages ............................................62
8.3 FDL SAPs ...................................................69
8.3.1 SAP Receive Buffers ...........................70
8.3.2 SAP Transmit Buffers ..........................71
8.3.3 Receiving Broadcast/Multicast
Messages ............................................71
8.4 FDL Diagnostic Counters ............................74
8.5 FDL Network Parameters ...........................75
8
7
6
